150 ton Minster P2-150-60 Piece-maker Highspeed Press

Brand

MINSTER

Model

P2-150-60

Year

1975

Stock #

2688

Condition

Very Good

Request a Quote

Specifications

Tonnage

150

Stroke

6 inches

Shut Height

24 inches

Adjustment

4 inches

Bed Size

60" x 40"

Ram Area

60" x 23"

SPM

45-90

Standard Specifications
150 ton Capacity
Model# P2-150-60 Piece-Maker
Serial Number 21390
6" Stroke
24" Shut Height
4" Motorized Adjustment
60" LR x 40" FB Bed Area
60" LR x 23" FB Slide Area
45-90 VSPM

Equipment and Features
Air Clutch and Brake
Air Counterbalances
Monitor Flow Lubrication System
Motorized Slide Adjustment
6" Thick Bolster Plate
62" Distance Between Gibs
42" Distance from Floor to Top of Bed
T-Slotted Ram and Bolster
Light Curtains
20" Wide Windows
Palm Buttons
Floor Standing

Includes: Perfecto 600-18, 18" Wide Servo Feed With Indramat Controls
18" @ .140" Overall Width Capacity
 6" @ .225 Maximum  Material Thickness

Attachments

150 ton Minster P2-150-60 SG Press Stock#2688.jpg Download
